Description
General
| Frequency Coverage | A Band / B Band |
108.000 ~ 500.000 MHz |
|---|---|---|
| BC BAND | USA : 88.000 ~ 108.000 MHz
EUR : 76.000 ~ 108.000 MHz |
|
| Mode | AM, FM, WFM (F3E, A3E) | |
| Antenna impedance | 50 Ω(SMA) | |
| Number of memory channels | 2000 regular memory channels, 200 auto memory channels, 25 scan edges, 100 skip channels | |
| Frequency stability | Less than ±2.5 ppm on the basis of 25 ℃ (-20 ℃ ~ 60 ℃) | |
| Tuning steps | 5/6.25/8.33/10/12.5/15/20/25/30/50/100/125/200 kHz *On 108.000 MHz ~ 136.991 MHz, you can select only 8.33 kHz or 25.0 kHz |
|
| Battery requirement | 3.6 V DC (BP-287) | |
| Operation time | 10 hours (Dual display mode, continuous receiving in A band and standby in B band, Auto power save function On), AF output power : Vol level 20 in internal speaker, GPS ON, Bluetooth® OFF) | |
| External power supply | 5.0 V DC ±5 % (USB charging) | |
| Current drain (at 3.6V DC) | Rated audio : 380 mA typical | |
| Standby : 150 mA typical | ||
| Power save : 80 mA typical (FM mode, Single display mode, Record function Off, GPS Off, Backlight Off) | ||
| Dimensions (W x H x D) | 58 x 116 x 33.8 mm, 2.28 x 4.57 x 1.33 in (Projections not included) | |
| Weight (approximate) | 260 g, 9.17 oz (with supplied antenna and batteries) 150 g, 5.29 oz (without supplied accessories) |
|
| Usable temperature range | -20℃~60℃, -4℉~140℉ | |
Receiver
| Receiving system | Double conversion superheterodyne | |
|---|---|---|
| Intermediate frequency | A Band / B Band |
58.050 MHz/450 kHz (1st IF/2nd IF) |
| BC- BAND | 57.150 MHz/450 kHz (1st IF/2nd IF) | |
| Sensitivity | AM (10dB S/N : 1kHz Dev/30% Mod) |
108.000 ~ 142.000 MHz: Less than 0 dBμ 222.000 ~ 249.995 MHz: Less than 0 dBμ 250.000 ~ 299.995 MHz: Less than 5 dBμ 300.000 ~ 400.000 MHz: Less than 3 dBμ |
| FM (12dB SINAD : 1 kHz/3.5 kHz Dev) |
108.000～249.995 MHz: Less than -8 dBμ 250.000～299.995 MHz: Less than -3 dBμ 300.000～500.000 MHz: Less than -5 dBμ |
|
| WFM (12dB SINAD : 1 kHz / 52.5kHz Dev) | 76.000～108.000 MHz: Less than 0 dBμ | |
| Selectivity | AM / FM | More than 50 dB |
| WFM | More than 35 dB | |
| Audio output power (at 3.6V DC) |
Internal Speaker | More than 400 mW (8 Ω, 10 % distortion) |
| External Speaker | More than 40 0mW (8 Ω, 10 % distortion) | |
Supplied Accessories
- FA-S270C Antenna
- BP-287 Li-Ion Battery Pack
- MB-127 Belt Clip
- OPC-2480 USB Type-C™ cable
- Hand strap
