Description
General
| Frequency coverage (Differs according to version) |
0.100–1309.995MHz* |
|---|---|
| Mode | AM, FM, WFM |
| Frequency stability | ±1.0ppm (at 25°C) |
| Current drain | Rated audio output: 130mA typ. (Ext. SP, backlight off) |
| Battery pack or cells | 2×R6 (AA) size Ni-MH or alkaline cells |
| External power supply requirement | 4.5V DC rated (4.5 – 6.3V with BC- 196SA/SD, CP-18A/E) |
| Antenna impedance | 50Ω (SMA) |
| Number of memory channels | 1550 (1300 regular, 200 auto memory write and 50 scan edges) |
| Dimensions (W×H×D; Projections are not included) |
58×86×29.8 mm; 2.28×3.39×1.17 in |
| Weight (approx.) | 200g; 7.1oz |
| Sensitivity (typical, except spurious points) |
FM (at 12dB SINAD): | 1.625MHz– 4.995MHz 0.32μV typ. 5.000MHz– 29.995MHz 0.25μV typ. 30.000MHz– 117.995MHz 0.18μV typ. 118.000MHz– 246.995MHz 0.18μV typ. 247.000MHz– 469.995MHz 0.18μV typ. 470.000MHz– 832.995MHz 0.32μV typ. 833.000MHz–1029.995MHz 0.28μV typ. 1030.000MHz–1309.995MHz 0.35μV typ. |
|---|---|---|
| WFM (at 12dB SINAD) | 76.000MHz– 108.000MHz 1.1μV typ. 175.000MHz– 221.995MHz 1.1μV typ. 470.000MHz– 770.000MHz 1.8μV typ. |
|
| AM (at 10dB S/N): | 0.495MHz– 4.995MHz 1.3μV typ. 5.000MHz– 29.995MHz 0.89μV typ. 118.000MHz– 136.000MHz 0.63μV typ. 222.000MHz– 246.995MHz 0.63μV typ. 247.000MHz– 329.995MHz 0.79μV typ. |
|
| Selectivity | AM, FM: | More than 12kHz/–9dB, Less than 30kHz/–60dB |
| WFM | More than 150kHz/–6dB | |
| AF power (at 10% distortion) | Internal speaker (16Ω load) More than 150mW External speaker (8Ω load) 80mW typ. |
|
| External speaker connector | 3-conductor 3.5 (d) mm (1⁄8″)/8Ω | |
* Cellular bands are blocked in the USA version.
Applicable U.S. Military Specifications
Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.
| Standard | MIL-810 G | |
|---|---|---|
| Method | Procedure | |
| Low Pressure | 500.4 | I,II |
| High Temperature | 501.4 | I,II |
| Low Temperature | 502.4 | I,II |
| Temperature Shock | 503.4 | I |
| Solar Radiation | 505.4 | I |
| Humidity | 507.4 | – |
| Vibration | 514.5 | I |
| Shock | 516.5 | I,IV |
Also meets equivalent MIL-STD-810-C, -D -E and -F.
Ingress Protection Standard
| Water | IPX2 (Drip resistant) |
|---|
All stated specifications are subject to change without notice or obligation.
Supplied Accessories
- Ni-MH cells*
- AC adapter, BC-196SA/BC-153SE*
- Antenna
- Belt clip
- Handstrap
* Not supplied depending on version
