Description
General
| IC-FR9010 | IC-FR9020 | |||
|---|---|---|---|---|
| Frequency coverage (Varies according to version) |
146–174MHz | 440–475MHz | ||
| Number of channels | Max. 500 channels | |||
| Channel spacing (Varies according to version) |
12.5/20/25/30kHz* | |||
| Type of emission | 16K0F3E*, 11K0F3E, 8K10F1E/F1D | |||
| Power supply requirement | 13.6V DC nominal | |||
| Current drain (at 13.6V DC) |
Tx | High | 16A | 18A |
| Rx | Stand-by | 280mA | ||
| Max. audio | 3A | |||
| Dimensions (projections not included; W×H×D) |
482×88×413 mm ; 18.98×3.46×16.26 in |
|||
| Weight (approx.) | 11.0kg ; 24.3lb | |||
Transmitter
| IC-FR9010 | IC-FR9020 | ||
|---|---|---|---|
| RF output power (100% duty cycle) |
High | 110W | 100W |
| Low | 50W | 50W | |
| Spurious emissions | 80dB min. | 76dB min. | |
| Max. frequency deviation | ±5.0kHz/±2.5kHz (W/N) | ||
| Audio harmonic distortion | 3% typ. (60% deviation) | ||
| FM hum and noise | 55/50dB min. (W/N) | ||
Receiver
| IC-FR9010 | IC-FR9020 | ||
|---|---|---|---|
| Sensitivity | at 12dB SINAD | 0.30μV typ. | |
| at 5% BER | 0.30μV typ. | ||
| Adjacent channel selectivity | 82/76dB min. (W/N) 55dB min. (Digital) |
80/72dB min. (W/N) 55dB min. (Digital) |
|
| Spurious response rejection | 95dB min. (W/N) 83dB min. (Digital) |
85dB min. (W/N) 83dB min. (Digital) |
|
| Intermodulation rejection | 79dB min. (W/N) 79dB min. (Digital) |
77dB min. (W/N) 77dB min. (Digital) |
|
| AF output power (at 5% distortion) | 7.5W typ. with 8Ω load | ||
* 25kHz bandwidth is no longer available for FCC Part 90 licensees for USA versions.
Ask your dealer if you need 25kHz bandwidth.
Applicable U.S. Military Specifications
Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.
| Standard | MIL-810 G | |
|---|---|---|
| Method | Procedure | |
| High Temperature Storage | 501.5 | I |
| High Temperature Operation | 501.5 | II |
| Low Temperature Storage | 502.5 | I |
| Low Temperature Operation | 502.5 | II |
| Vibration | 514.6 | I |
| Shock Functional | 516.6 | I |
Also meets equivalent MIL-STD-810-C, -D, -E and -F.
All stated specifications are subject to change without notice or obligation.
