Description
General
IC-FR5000 |
IC-FR6000 |
|||
|---|---|---|---|---|
| Frequency coverage (Varies according to version) |
136-174 MHz | 400-470 MHz | ||
| Number of channels | 32 ch | |||
| Channel spacing (Varies according to version) |
6.25/12.5/25 or 7.5/15/30 kHz | |||
| Type of emission | 16K0F3E, 11K0F3E, 11K0F7E/D/W, 8K50F3E, 4K00F1E/D, 4K00F3E |
16K0F3E, 11K0F3E, 11K0F7E/D/W, 4K00F1E/D, 4K00F3E |
||
| Power supply requirement | 13.6V DC | |||
| Current drain (at 13.6V DC) |
Tx High | 15A | ||
| Rx | Stand-by | 500mA*1 | ||
| Max. audio | 1900mA | |||
| Dimensions (projections not included; W×H×D) |
483×88×260 mm 19.02×3.46×10.24 in |
|||
| Weight (approx.) | 5.6kg; 12.3lb | |||
*1 Repeater operation only.
Transmitter
IC-FR5000 |
IC-FR6000 |
|
|---|---|---|
| RF output power (High) | 50W | |
| Spurious emissions | 80dB | |
| Frequency stability | ±0.5ppm | |
| Audio harmonic distortion | 1% typical 40% deviation |
|
| FM Hum and Noise | 52dB typ. (W) 49dB typ. (N) |
50dB typ. (W) 45dB typ. (N) |
| Digital FSK error | 5% max. | |
Receiver
IC-FR5000 |
IC-FR6000 |
||
|---|---|---|---|
| Sensitivity | FM at 12dB SINAD | 0.25µV (typ.) | |
| Digital at 5% BER | 0.20μV (typ.) | ||
| Adjacent channel selectivity (W/N) | 78/56dB typ. | ||
| Spurious response rejection | 90dB typ. | ||
| Intermodulation rejection | 78dB typ. | ||
| AF output power (at 5% distortion) | 4.0W (typ.) with a 4Ω load | ||
Function Comparison and Internal Unit Options
IC-FR5000
|
||
|---|---|---|
| Type-C multi-site trunking | N/A | |
| Type-D multi-site trunking | UC-FR5000 Version 03 | |
| Type-D single-site trunking | UC-FR5000 Version 01 | |
| LTRTM Tranking | available*1 | |
| Multi-site Conventional | UC-FR5000 Version 02 | |
| Voice Scrambler (Digital) | available | |
| DES Encription | N/A | |
| AES Encription | N/A | |
| Voice Scrambler (Analgue)*2 |
Inversion | available |
| CTCSS/DTCS | encoder | available |
| decoder | available | |
| 2-Tone | encoder | N/A |
| decoder | N/A | |
| 5-Tone | encoder | available |
| decoder | available | |
| DTMF autodial | available | |
| DTMF decoder | available | |
| BIIS 1200 | – | |
| MDC 1200 | – | |
*1 External controller required.
*2 Inversion type voice scrambler is not compatible with UT-109R/UT-110R voice scrambler.
Applicable U.S. Military Specifications
Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.
| Standard | MIL-810 F Method, Proc. |
|---|---|
| High Temperature Storage | 501.4 I |
| High Temperature Operation | 501.4 II |
| Low Temperature Storage | 502.4 I |
| Low Temperature Operation | 502.4 II |
| Vibration | 514.5 I |
| Shock Functional | 516.5 I |
All stated specifications are subject to change without notice or obligation.
